DORSEY 55 TON DETACH

Read More...

2019 DORSEY 55 TON DETACH

Construction
Description: 55 Ton Detach Triple Axle Dominator Detachable Neck Lowboy CAPACITY 55 Tons in 12' Concentrated Load / 55 Tons in 16' 3+1 Concentrated Load OVERALL LENGTH 53' OVERALL WIDTH 8' 6" DECK LENGTH 25' DECK HEIGHT 22" Loaded DECK FLOORING Apitong - 1 1/2" - Covering Outside Only MAINBEAMS 16" Fabricated I-Beams - Positive Camber SIDE RAILS 14" Fabricated I-Beams - Positive Camber CROSS MEMBERS 10" I-Beam on 24" Centers GOOSENECK Non-Ground Bearing Hydraulic Detachable Neck - Set up for Wetline KING PIN SETTING 16" KING PIN SWING RADIUS 102" STD KING PIN HEIGHT 50" ( 4 Postions - Deck Heights 24", 22", 20", 18") BOOM TROUGH Open - "V" Crossmembers FRONT LOADING RAMP None / Tapered Front Slope w/ Traction Bars D RING 16 WIDENING BRACKET 11 Pair of 12" Brackets (extends deck width 2') TOOL BOX Tool Box in Front of Deck with Lockable Lid AXLE (3) 25,000 lb. Capacity w/ 54 1/2" Axle Spacings, Auto Slack, SUSPENSION Watson - Air Ride - Lift Rear Axle REAR AXLE FLIP: Plumbed and Pinned for 4th Axle/Available at an additional $15,000 cost (Weighs 2,500 lbs) WHEELS Steel (Outer aluminums available at Additional $2000) TIRES 275/70R22.5 WIRING D.O.T Sealed Wiring Harness LIGHTS STD w/ Amber Strobes in Bumper (Change 2 in Center) PONY MOTOR-13 HP Honda WHEEL WELL-Covered with Steel Check Plate Call for Factory Freight Quote FET INCLUDED
  • Item #: 55TONDORSEYDETACH
  • Length:  53'x102"
  • Single/Tandem/Spread:  TRIPLE
  • Suspension:  AIR RIDE W/3RD AXLE LIFT
  • Weight Rating:  13HP HONDA PONY MOTOR
  • Unit Info: 2019 DORSEY 55 TON DETACH
  • Assembly Info: DORSEY 55 TON DETACH
  • Wheels: Steel
  • Tires: LP255/70R22.5
  • Brakes: Air
  • Pin type / setting: 16"
  • Width: 102"
  • LED Lights: Yes
  • Suspension Details: Air Ride
  • Length Details: 53'
  • Side Height: 22" Loaded
  • Mid Turn Lights: Yes
  • Frame or Frameless: Frame
  • Length: 53'x102"
  • Single/Tandem/Spread: TRIPLE
  • Suspension: AIR RIDE W/3RD AXLE LIFT
  • Weight Rating: 13HP HONDA PONY MOTOR
  • All Unit Items

Attachments:
DorseyLB55-51_Detachable_Lowboy_web.pdf
Vander Haags Inc
3809 4th Ave W
Spencer, IA

888-940-5030
We have transportation quotes and financing available. Call to find out how we can help you!
Price: $60900.00
